Creating templates for Daz products in Blender.

Philippi_ChildPhilippi_Child Posts: 680
edited August 30 in Blender Discussion

[Creating templates for Daz  products in Blender.] How is this done since blender can not read .duf files?

Post edited by Richard Haseltine on

Comments

  • PadonePadone Posts: 4,309

    Not sure what you mean about templates, but you can read duf files with python. One way is to use the diffeomorphic library.

    https://github.com/Diffeomorphic/import_daz/wiki/Scripting_DAZ_Importer_Operators

  • Philippi_ChildPhilippi_Child Posts: 680

    Thank you so much. But I'm afraid none it makes sense to me. I'll just use a texture from the product to create my own texture.

  • PadonePadone Posts: 4,309
    edited August 31

    Ok so for "template" I guess you mean the uv map. For this it's enough to export as obj in daz studio.

    steps:

    1. in daz studio export as obj
    2. import in blender
    3. edit mode: uv editor > uv > export uv layout

    p.s. Or in DS4 you can see the uv map in the viewport panel, selecting the "uv view", but it will be displayed at the viewport resolution. Then you can print the screen and manipulate with a paint program, eventually. The blender way is more precise as it allows to export the uv map at the desired resolution.

    p.s. In blender you can also paint directly over the 3d model, that's often easier because you don't care of the uv seams.

    Post edited by Padone on
